I have had a lot of questions regarding how I scratch build tanks for my Rebel Grot army, so I decided to write a tutorial as I build my Devil Dog. Once I get moving it’s easy to forget to take pictures. Please let me know if there is a step where you would like to see more pictures. I’ll need to build a couple more Chimeras soon, and they’re very close to the Devil Dog kit, so I can fill in gaps later.
First of all, why scratch build tanks?
There are a lot of reasons to scratch build tanks. You may be looking to save some money. Material costs can add up more than you might expect, depending on what you’re using, but you will probably still come out way ahead in cost. If you go all out on high quality materials you could spend as much as $10 on a single tank, but if you’re frugal it will probably be closer to a buck or two.
In either case you’re way below $65. It’s also common to scratch build tanks because you want something different from the standard kit. For me it’s a healthy mix of the two.
If you are looking for an easy route then scratch building is the wrong way to go. The toughest GW kit I’ve assembled was still easier than anything I’ve scratch built. However, it might not be as tough as you think.
For my builds I want something that looks like an Imperial vehicle that has been commandeered by Orks or Grots. By the time I were to cut off what I didn’t want and slap on what I did, I think it would be about as much work to do a good conversion as it is to scratch build. Since I’m looking at a similar amount of work either way I figure I might as well go the cheap route!
If you want something that looks exactly like the official kit then you should seriously consider whether you’d rather spend the time or the money.
I’m going to scratch build, so what do I need?
For any scratch build you should have a pattern to work from. This makes it easier to ensure you get the sides equal and everything square. I’ve drawn my own in the past. My battlewagon is an example of this:
For my Rebel Grots I’ve been using papercraft templates I found online*. If you look for templates made by Eli Patoroch you’ll find some really good stuff. I don’t know who he is but he’s made a ton of templates!
These provide a detailed build that looks very much like the GW kits when assembled. For this tutorial I’ll be working with his Hellhound template.
*Note: Finding the templates has become difficult since writing this. However, I have uploaded the template I’m using to the blog.
You will need to decide what to use for materials. Styrene sheet, or plasticard, is very popular and for very good reasons. It is fairly cheap, quite durable, and can produce fantastic results. It can take a little getting used to but overall it is easy to work with.
One nice thing about styrene is that it’s the same material used for the plastic GW kits so the end result will have very similar weight to the actual kit. It will also take paint, glues, etc. the same way as the kits you are used to working with. I also like that you can drill and cut into it to create battle damage. I did my first Basilisk with plasticard:
For this tutorial I am starting with cheap card stock. The templates were printed on 110lb. index card stock so the pieces will have a bit of definition on their own. A lot of papercrafters stop at that as it’s reasonably durable once it’s glued together. I want mine to be a bit more durable though as I’ll be adding plastic bits later.
For the primary structure I’m using some high end materials looted from my recycling bin:
Yeah, it seems a bit trashy (pun intended) but it works pretty well if you know how to work with it. If you use some plasticard armor plates over the card stock core it’s difficult to tell from a pure plasticard build once it’s painted. You can see that with my two Leman Russ Exterminators below:
Another material that works well is matboard. It’s a heavy card stock used for framing. It can be tough to cut because it’s so thick, but it is durable. The battlewagon showed above is a matboard core clad in styrene armor plates.
So, for this build I’ll be using cereal box, index card stock, and styrene to build most of the tank. I also use a lot of random styrene rods and bits for detail. GW weapons and vehicle bits are great if you have them handy.
Here’s a quick list of the other items I’ll be using:
- Hobby Knife
- Super Glue
- PVA glue (I use Modge Podge)
- Glue Stick
- Steel Ruler
- Cutting Mat or Board
- Green Stuff (Kneadatite Epoxy Putty)
- GW Liquid Green Stuff
- Hole Punches (1/4″, 1/8″, 1/16″)
- Maybe some other random stuff I’m forgetting…
You should definitely check out Thor’s article on hobby supplies everyone needs. It covers a lot of the items above.
So, now you’ve got a list of junk to round up if you want to follow along. In the next part of the series I’ll explain how I turn that cardboard and paper into a basically tank shaped structure. After that we’ll start adding the details that will make it less like a box and more like a proper tank!
Scratch Building Tanks
|1. Gathering Supplies|
2. Basic Structure
3. Turret, Armor Plates & Rivets
4. Beyond the Template
|6. Multi-melta & Metal Cannon|
7. Finishing Touches
9. Devil Dog vs Chimera #1
10. Devil Dog vs Chimera #2
- How to Make a Wargaming Table & Terrain Cheaply & Easily - November 6, 2017
- First Rebel Grot Armored Sentinel Painted! - December 19, 2016
- Assassinorum Execution Force Product Review from Games Workshop - May 6, 2015
This will be a cool series. Good idea.
Thanks. I hope people find it useful. This post is more of an introduction than anything but the next one should be more informative.
Question on 4Shared…my virus scanner goes insane when I attempt to download anything from there. Do you get the same thing? I was trying to nab a pattern for a half-scale boltgun, but kept getting red flags from my scanner.
I know he, Kamui, ended up with some spyware after visiting that site so I’m not surprised.
Yeah, any mass sharing site is a little risky. I do recommend you keep your virus protection up to date.
hey, just a question, are you aware of any good hovertank templates?
I’ve seen a couple of Warhammer skimmers such as Wave Serpents and Pirahna. I haven’t built or even looked very closely at these templates so I don’t know how good they are.
This looks like it could be a great series. Looking forward to it. I have a landraider protos I would love go turn into a phobos.
Not sure if you noticed, but the series is complete – series nav at the top of the article. I dug this up for social media because it’s a great tutorial, all 10’ish parts of it. Then again, you saying “looking forward to it” could simply mean you reading it. Either way, enjoy :)
I wish I had the time to read all ten in a go.
I think this series contains my most popular articles. I hope you enjoy catching up on them :)
Not only that, some of the most popular ones on the entire blog.
How would you go about templates and plasticard?.
I use .030 or .040 plasticard for the structural portions and thicker plates, then I use .020 and .010 for the thinner detail layers.
I print the templates on regular copier paper instead of using the more expensive card stock that I used for this tutorial. I rough cut the pieces and glue them to the plasticard like I did in the next section of the tutorial. I usually use a glue stick for this because it grabs quickly and will hold the template to the plasticard while I cut it out but it peels cleanly off of the plasticard afterward. Because I peel the paper off between layers I don’t have the template to help line up subsequent layers so I scribe the corners through the template with a pin to mark the styrene before pulling them apart. The glue stick bond is brittle so sometimes the pieces want to come apart before everything is scored. Rubber cement might be better for this but I haven’t tried it yet.
Of course, styrene won’t bend like cardboard does. With a thicker sheet you might be able to score and carefully bend up to 90 degrees without separating the pieces but I usually score and snap where it would fold then glue the edges together. The tabs meant to be folded under and glued won’t do any good so I cut them off when cutting out the template, but I replace some of them with pieces of square rod to more easily align the pieces and create a stronger join.
